Aleación de Incoloy
Created with Pixso. Copper Nickel Pipe Industry Nickel Based Alloy Incoloy 800 Tube 690 MPa

Copper Nickel Pipe Industry Nickel Based Alloy Incoloy 800 Tube 690 MPa

Nombre De La Marca: Runlai
Número De Modelo: Incoloy 800
MOQ: 10 kilos
Precio: Negociable
Tiempo De Entrega: 20~40 días
Condiciones De Pago: L/C, T/T, Western Union, MoneyGram
Información detallada
Lugar de origen:
China.
Certificación:
ISO9001 ROHS
Nombre del producto:
Tubo de Incoloy 800
El material:
Ni Cr Fe
Ni (min):
El 30%
Densidad:
7,94 g/cm3
Punto de fusión:
1,370°C
Elongación (≥ %):
el 30%
Fuerza de rendimiento:
205-240 MPa
Resistencia a la tracción:
520 a 690 MPa
Estándar:
Las demás especificaciones
Aplicación:
Fabricación de calderas, intercambiadores de calor, tuberías de generadores de vapor, etc. en la ind
Detalles de empaquetado:
Envasado en una caja de cartón, envuelto en una bobina con una bolsa polivalente, luego en una caja
Capacidad de la fuente:
300 toneladas al mes
Resaltar:

Copper Nickel Pipe Incoloy 800 Tube

,

Nickel Based Alloy Incoloy 800 Tube

,

690 MPa Incoloy 800 Tube

Descripción de producto

Copper Nickel Pipe Industry Nickel Based Alloy Incoloy 800 Tube 690 MPa





Product Introduction


Incoloy 800 tube is a high performance nickel-based alloy tube with excellent high temperature corrosion resistance and good mechanical properties, widely used in the power industry. Its main chemical components include nickel (Ni) 30-35%, chromium (Cr) 19-23%, iron (Fe) balance, etc. These components give it excellent oxidation and corrosion resistance at high temperatures. The physical properties of Incoloy 800 tube include density 8.0 g/cm³, melting point 1350-1400°C, tensile strength 450 MPa, yield strength 180 MPa, and elongation 30%. This alloy pipe can still maintain good mechanical properties and anti-oxidation properties in high temperature environments, and is suitable for manufacturing boilers, heat exchangers, steam generator pipes and other equipment in the power industry. Its good processing and welding properties enable it to be formed through conventional processing technology, making it suitable for manufacturing parts with complex structures. Incoloy 800 tube is strictly implemented in accordance with ASTM B407, B514, B515 and other standards, ensuring its stability and reliability in high temperature and high pressure environments. In the power industry, Incoloy 800 tube can significantly improve the service life and operating efficiency of equipment and reduce maintenance costs. It is an indispensable and important material in power production.



Parameter


Main ingredients: nickel (30-35%), iron (39.5% minimum content), chromium (19-23%), copper (0.75% maximum content), aluminum (0.15-0.60%), carbon (0.1% maximum content)
Density: 7.94 g/cm3
Melting point: 1350-1400 degrees Celsius
Yield strength: ≥240 MPa
Tensile strength: ≥600 MPa
Thermal expansion coefficient: 13.9 x 10^-6/degrees Celsius (range 20-100 degrees Celsius)



Incoloy Ni Cr Fe C Mn S Si Cu Al Ti
800 30.0-35.0 19.0-23.0 39.5min 0.10max. 1.50max. 0.015max. 1.0max. 0.75max. 0.15-0.60 0.15-0.60



AMS Number Alloy Type UNS Cross Ref. Spec Misc./Shape
AMS 5766 Bar Incoloy 800 Nickel N08800 - Bar
AMS 5766 Custom Tube Incoloy 800 Nickel N08800 - Custom Tube
AMS 5871 Plate Incoloy 800 Nickel N08800 - Plate
AMS 5871 Sheet Incoloy 800 Nickel N08800 - Sheet
AMS 5871 Strip Incoloy 800 Nickel N08800 - Strip



Specific Applications


  1. Superheater and reheater tubes: In thermal power plants, superheaters and reheaters are used to heat steam to a higher temperature to improve power generation efficiency. Incoloy 800 tubes can maintain stable performance at high temperatures, have good oxidation resistance and creep resistance, and are suitable for manufacturing superheater and reheater tubes.
  2. Nuclear reactor cooling pipes: In nuclear power plants, the cooling pipes of nuclear reactors need to withstand high temperature, high pressure and radiation environments. Incoloy 800 tubes have good corrosion resistance and oxidation resistance, which can meet the use requirements of nuclear reactor cooling pipes and ensure the safe operation of nuclear power plants.



Advantages and Characteristics


  • High strength and toughness: Incoloy 800 pipe has a tensile strength of at least 520 MPa, a yield strength of at least 205 MPa, and an elongation of at least 30%.
  • Good ductility: With good ductility, it is easy to process and form, and is suitable for various processing processes such as forging, hot rolling, cold working and welding.
  • Good machinability: Incoloy 800 pipe can be processed and formed by a variety of traditional methods, such as casting, forging, rolling and welding. Although the alloy is easily work-hardened, it can be successfully spun, deep drawn, pressed or punched after proper treatment.
  • Excellent weldability: Incoloy 800 alloy is easy to weld, and the welded joints show excellent corrosion resistance and mechanical properties. No solution treatment is required after welding, which simplifies the processing process and reduces manufacturing costs.

Contact Us

Email:fbwlau@cnrunlai.com

Oem service:
Welcome customized size
We are experience factory for OEM&ODM service



Related Questions and Answers


1. What are the application areas of Incoloy 800 pipes?
Widely used in industries such as petrochemicals, nuclear energy, aerospace, marine engineering, and pharmaceutical food processing.

2. What are the advantages and characteristics of Incoloy 800 pipes?
High temperature corrosion resistance, stress corrosion resistance, good mechanical properties and processing performance.

3. How does Incoloy 800 pipe compare with other materials?
Better than ordinary stainless steel and Inconel 600, and slightly inferior to Incoloy 800H/800HT in high temperature stability and creep resistance.

4. Can Incoloy 800 pipes be customized?
Customized size, wall thickness and length are available.

5. How is Incoloy 800 pipe packaged?
It is packaged in wooden boxes and plastic films with labels and logos.



Copper Nickel Pipe Industry Nickel Based Alloy Incoloy 800 Tube 690 MPa 0Copper Nickel Pipe Industry Nickel Based Alloy Incoloy 800 Tube 690 MPa 1
